Chapman Valve Mfg. Co.- Indian Orchard, MA
List 82s - Part 3

  List 82 (~1902 to ~1910)
These List 82s continue with the "large barrrel, large bonnet" style with exceptions noted as "sbsb" (small barrel, small bonnet) with the V.O. size.
  • Bonnet: fluted underside, CHAPMAN VALVE MFG. CO. SPRINGFIELD, MASS. on top with opening direction. Some can be found with ...BOSTON, U.S.A. instead.
  • Logo: the same 8-point "snowflake" surrounding the rounded letters "C" and "V" on top of each other with "M'FG. CO. " in the very middle. "CHAPMAN VALVE BOSTON U.S.A." on the circle in the "snowflake" as shown at the left.
  • Nozzles: screw-in (note LARGE diameters on barrel where 2 1/2" hose nozzles screw in). The large diameter may have been intended to accommodate 3" nozzles.
  • 0943
    Nozzles: 2x 2"
    Size: 4" V.O.
    1726
    Nozzles: 2x 2", 1x 5"
    Size: 4" V.O.
    Note: wrong bonnet
    Location: Massachusetts
    0816
    Nozzles: 2x 2"
    Size: 5" V.O.
    0936
    Nozzles: 3x 2"
    Size: 5" V.O.
    Location: Massachusetts
    0851
    Nozzles: 2x 2", 1x 4"
    Size: 5" V.O.
    0853
    Nozzles: 2x 2", 1x 5"
    Size: 5" V.O.
    Location: Massachusetts
    0815
    Nozzles: 1x 2", 2x 5"
    Size: 5" V.O.
    1007
    Nozzles: 1x 2", 2x 5"
    Size: 5" V.O.
    Location: Massachusetts
    0849
    Nozzles: 1x 2", 2x 5"
    Size: 5" V.O.
    Location: Massachusetts
    1346
    Nozzles: 3x 2"
    Size: 6" V.O.
    Location: Rhode Island

      List 82 (externally gated)
    These "lblb" List 82s are unique in that they have bolt-on gate valves for the hose nozzles. They are listed separately because everything else on this page is listed by whether they have LARGE or SMALL diameters on the barrels where the nozzles screw in.
  • Their vintage is believed to be ~1910.
  • Other Chapman hydrants with bolt-on gate valves can be found on the Multiple Valve page.
  • 1349
    Nozzles: 2x 2"
    Size: 5" V.O.
    2113
    Nozzles: 3x 2"
    Size: 6" V.O.
    Location: private collection
    1348
    Nozzles: 4x 2"
    Size: 6" V.O.
    Location: Massachusetts

      List 82 (~1910 and later)
    These List 82s represent the nearly the end of the evolution of the model; and they differ from the above 1902-1910 group only by having SMALL diameters on barrel where hose nozzles screw in. They are the "large barrel, large bonnet" style; with "sbsb" exceptions grouped separately below.
    2028
    Nozzles: 1x 2"
    Size: ?

    Photo © 2003 Meg Ormiston
    0813
    Nozzles: 2x 2"
    Size: 4" V.O.
    1797
    Nozzles: 3x 2"
    Size: 4" V.O.
    Location: Massachusetts
    0944
    Nozzles: 2x 2", 1x 5"
    Size: 4" V.O.
    0850
    Nozzles: 2x 2"
    Size: 5" V.O.
    0947
    Nozzles: 3x 2"
    Size: 5" V.O.
    0819
    Nozzles: 2x 2", 1x 4"
    Size: 5" V.O.
    0852
    Nozzles: 2x 2", 1x 4" (casting made for 5")
    Size: 5" V.O.
    0818
    Nozzles: 2x 2", 1x 5"
    Size: 5" V.O.
    0817
    Nozzles: 1x 2", 2x 5"
    Size: 5 V.O.
    0946
    Nozzles: 1x 2", 2x 5"
    Size: 5 V.O.
    1342
    Nozzles: 2x 2"
    Size: 6 V.O.
    Location: Massachusetts
    0820
    Nozzles: 3x 2"
    Size: 6" V.O.
    2172
    Nozzles: 3x 2"
    Size: 6" V.O.
    0945
    Nozzles: 2x 2", 1x 5"
    Size: 6" V.O.
    Location: Massachusetts
    2194
    Nozzles: 4x 2"
    Size: 6"V.O.

    These "sbsb" List 82s have a mixture of features from different vintages.
    1343
    Nozzles: 2x 2" leaded-in
    Size: 3" V.O.
    Logo style: 1890-1900
    2417
    Nozzles: 2x 2" leaded-in, 1x 4", screw-in
    Size: 5" V.O.
    Logo style: 5A
    2372
    Nozzles: 2x 2" leaded-in, 1x 4", screw-in
    Size: 4" V.O.
    Logo style: 1890-1900
    0848
    Nozzles: 2x 2", 1x 5"
    Size: 6" V.O. sbsb
    Logo style:5A
    Note: only "Open" on bonnet top
    Location: Massachusetts
    1263
    Nozzles: 2x 2" screw-in
    Size: 4" V.O.
    Logo style: 1890-1900
    2554
    Nozzles: 2x 2" screw-in
    Size: 4" V.O.
    Logo style: post 1900, on the sides.
    1350
    Nozzles: 2x 2" screw-in
    Size: 5" V.O.
    Logo style: post 1900 (Boston U.S.A)
    0830
    Nozzles: 2 x 2", 1 x 5" screw-in
    Size: 5" V.O.
    Logo style: post 1900 (Boston U.S.A)

      List 82 (~1920's)
    These last List 82s differ from the '1910 & later group' in that they have a further revised barrel logo.
  • Bonnet: same fluted underside
  • Logo: the same 8-point "snowflake" surrounding the rounded letters "C" and "V" on top of each other with "M'FG. CO. " in the very middle. "CHAPMAN VALVE SPRINGFIELD MASS." on the circle in the "snowflake" as shown at the left.
  • Nozzles: screw-in (note SMALL diameters on barrel where hose nozzles screw in)
  • 1347
    Nozzles: 3x 2"
    Size: 6"V.O.
    1709
    Nozzles: 4x 2"
    Size: 6"V.O.
    Location: Connecticut
    2352
    Nozzles: 2x 2", 1x 4"
    Size: 6"V.O.
