Rensselaer Valve - Troy, NY
List 90s - Part 3 (8-bolt bonnets)

  List 90s (8-bolt bonnet)
This List 90 variation has an bonnet with 8 bolts, indexed with one bolt inline with the "H" in "THE COREY". It has the same barrel size (~7" I.D., ~8" O.D.) and main valve opening (5") as the 5-bolt bonnet variation found on the previous page. All known hydrants have "rimmed" bonnets.
1371
Nozzles: 2x 2"
Barrel: 1 pc. w/o patents
Location: Massachusetts
Photo: © 2002, J. Kaminski
1901
Nozzles: 2x 2"
Barrel: 2 pc. w/o patents
Location: Eugene N. collection
Photo: © 2002, E. Newbry
1868
Nozzles: 2x 2" ext. gated
Barrel: ? pc.
Photo: © 2003 T. Ingalsbe
0957
Nozzles: 3x 2"
Barrel: 1 pc. w/o patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
0575
Nozzles: 2x 2", 1x 3"
Barrel: 1 pc. w/o patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
0481
Nozzles: 2x 2", 1x 5"
Barrel: 1 pc. w/o patents
Location: Massachusetts
Photo: © 2002, J. Kaminski
0990
Nozzles: 2x 2", 1x 5"
Barrel: 2 pc. w/o patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
1534
Nozzles: 2x 2", 1x 4"
Barrel: 2 pc. w/patents
Location: John A. collection
Photo: © 2002, J. Anderson
0958
Nozzles: 2x 2", 1x 5"
Barrel: 1 pc. w/o patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
1877
Nozzles: 2x 2", 1x 5"
Barrel: 1 pc. w/patents
Location: Jim S. collection
Photo: © 2003, J. Kaminski
0956
Nozzles: 3x 2", 1x 5"
Barrel: 1 pc. w/o patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
1372
Nozzles: 3x 2", 1x 5"
Barrel: 2 pc. w/o patents
Location: Jeff K. collection
Photo: © 2002, J. Kaminski
0860
Nozzles: 3x 2", 1x 5"
Barrel: 2 pc. w/o patents
Location: Jeff K. collection
Photo: © 2002, J. Kaminski

  List 90s (8-bolt bonnet ... but larger)
This largest size List 90 has a bonnet with 8 bolts, indexed on either side of the "H" in "THE COREY". Company literature calls this a 6" size hydrant but it has a 6" main valve opening. The barrel I.D. is ~8", and O.D. is ~9" measured near the ground line O.D. rib. All known hydrants have "rimmed" bonnets.
0576
Nozzles: 2x 3"
Barrel: 2 pc. w/o patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
0868
Nozzles: 2x 3" (leaded-in)
Barrel: 1 pc. w/patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
2262
Nozzles: 2x 3" (screw-in)
Barrel: 1 pc. w/patents
Location: Jeff K. collection
Photo: © 2004, J. Kaminski
1944
Nozzles: 2x 2", 1x ~4"
Barrel: 1 pc. w/patents
Source: 1910 Rensselaer catalog
0579
Nozzles: 1x 2", 2x 4"
Barrel: 1 pc. w/patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
0224
Nozzles: 4x 2"
Barrel: 1 pc. w/patents
Location: Private collection
Photo courtesy J. Kaminski
1945
Nozzles: 4x 2" ext. gated
Barrel: 1 pc.
Source: 1910 Rensselaer catalog
0991
Nozzles: 2x 2", 2x 5"
Barrel: 1 pc. w/patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
0859
Nozzles: 3x 2", 1x 5"
Barrel: 2 pc. w/o patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
0856
Nozzles: 4x 2", 1x 5"
Barrel: 2 pc. w/o patents
Location: Jeff K. collection
Photo: © 2001, J. Kaminski
0578
Nozzles: 4x 2", 1x 5"
Barrel: 2 pc. w/o patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
2094
Nozzles: 4x 2", 1x 5"
Barrel: 1 pc. w/patents
Location: Jeff K. collection
Photo: © 2006, J. Kaminski
1373
Nozzles: 4x 2", 1x 5"
Barrel: 1 pc. w/patents
Location: Massachusetts
Photo: © 2001, J. Kaminski
